Low Pressure Hexagonal Head Plug Pipe Thread Steel 1/2-14 * 1-1/8" [NPT]

Low Pressure Hexagonal Head Plug Pipe Thread Steel 1/2-14 * 1-1/8" [NPT]

Regular price 9.67 $ CAD
Regular price Sale price 9.67 $ CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Download

Choose these fittings when you want the same high-quality found in our low-pressure pipe fittings, but need more strength to handle higher pressures. The bolts have a thread of 1/2-14 and a length of 1-1/8.

Fittings that meet ANSI/MSS SP-114 adhere to high-quality standards for heat treating, material thickness, and marking. Black steel fittings have excellent corrosion resistance.

View full details

Specifications

Product Number BS3-05011-NPT
For Use With Air, Steam, Water
Shape Cap/Plug
Type Plug
Material Black Steel
Class 150
Fabrication Heat Treated
Connection Type Pipe
Connection Style Threaded
Connection NPT Male
Pipe Size 1/2
Maximum Pressure 300 psi @ 72° F
Maximum Steam Pressure 150 psi @ 360° F

For Pipe

Schedule 40
Material Black Steel

For Flange

Class 150
Material Black Steel
Specifications Met ANSI/ASME B1.20.1, ANSI/MSS SP-114, ASTM B351, ASTM B473
RoHS RoHS 3 (2015/863/EU) Compliant
REACH REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant
