Welding Hook jaune Painted Alloy Steel 4-1/2"

Welding Hook jaune Painted Alloy Steel 4-1/2"

26.90 $ CAD
26.90 $ CAD
Sale Sold out
Shipping calculated at checkout.
Title
Download

This hook has a weight load limit of 6600 lbs. It is made of jaune painted alloy stee and thus provide medium resistance to corrosion in both dry and wet environments. The hooks have a diameter of 4-1/2. The hooks are grade 80.

View full details

Specifications
Product Number CRO-03080-W-51
Material and/or Plating Yellow Painted Alloy Steel
System of Measurement Imperial

Product Specification
Type Welding
Usable For Leverage Yes
Width (F) 1-27/64"
Opening Width (P) 1-3/16"
Outer Width (L) 4-9/64"
Overall Length (W) 4-17/32"
Bottom Thickness (H) 1-3/16"
Bottom Min. Width (T) 15/16"

Strength Specifications
Work Load Limit 6600 Lbs
Security Factor 4 : 1
Ultimate Weight Load 26400 Lbs
