Welding Hook Yellow Painted Alloy Steel 1-1/4" [WLL : 22000 Lbs]

Welding Hook Yellow Painted Alloy Steel 1-1/4" [WLL : 22000 Lbs]

104.90 $ CAD
104.90 $ CAD
Sale Sold out
Title
Download

This hook has a weight load limit of 22000 lbs, an unltmate load limit of 88000 lbs. It is made of yellow painted alloy stee and thus provide medium resistance to corrosion in both dry and wet environments.

View full details

Specifications
Product Number CRO-12080-W-51
Material and/or Plating Yellow Painted Alloy Steel
System of Measurement Imperial

Product Specification
Type Welding
Usable For Leverage Yes
Width (F) 2-3/32"
Opening Width (P) 1-31/32"
Outer Width (L) 6-37/64"
Overall Length (W) 7-7/8"
Bottom Thickness (H) 2-11/64"
Bottom Min. Width (T) 1-17/32"

Strength Specifications
Work Load Limit 22000 Lbs
Security Factor 4 : 1
Ultimate Weight Load 88000 Lbs
