Serrated Flanged Conical Hexagonal Nut Black Oxide 5/8-11 Grade 8

Serrated Flanged Conical Hexagonal Nut Black Oxide 5/8-11 Grade 8

Regular price 6.70 $ CAD
Regular price Sale price 6.70 $ CAD
Sale Sold out
Quantity
Download

Price may change with quantity see chart under PROMOTIONS


An irregularly shaped thread at the top of the nut grips the bolt for a stronger hold than nylon-insert locknuts. They thread on from the bottom of the nut, allowing more threads to engage the bolt before tightening for easier installation than center-lock distorted thread locknuts. The strength of the bolt should match the strength of the nut to prevent damaging threads. They're not reusable. Comparable in strength to Grade 8 bolts, they're about 25% stronger than medium-strength steel locknuts.

Zinc-plated steel locknuts resist corrosion in wet environments.

View full details

Specifications

Product Number EEQ8-07000-N
Material Steel
Finish Black Oxide
Fastener Strength Grade/Class Grade 8
Thread Size 5/8 "-11
Thread Type UNC
Thread Spacing Coarse
Thread Fit Class 2B
Thread Direction Right Hand
Width 15/16 "
Height 35/64 "
Drive Style External Hex
Nut Type Locknut, Hex
Hex Nut Profile Standard
Locking Type Distorted Thread
Distorted Thread Type Top Lock
Flanged Serrations
System of Measurement Inch
RoHS RoHS 3 (2015/863/EU) Compliant
REACH REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant
DFARS Specialty Metals COTS-Exempt
