Specifications
| Product Number | EFCH-06000 |
| Material | Steel |
| Finish | Zinc Plated |
| Thread Size | 9/16"-18 |
| Thread Type | UNF |
| Thread Spacing | Fine |
| Thread Fit | Class 2B |
| Thread Direction | Right Hand |
| Width | 7/8" |
| Height | 31/64" |
| For Cotter Pin Diameter | 7/64" |
| Min. Slot Width | 0.15" |
| Min. Slot Depth | 0.163" |
| Drive Style | External Hex |
| Nut Type | Locknut |
| Hex Nut Profile | Standard |
| Locking Type | Cotter Pin |
| System of Measurement | Inch |
| RoHS | Compliant |
