Oval Head Metal Screw Full Thread Stainless Steel #6 * 1" [Square Drive]

Oval Head Metal Screw Full Thread Stainless Steel #6 * 1" [Square Drive]

0.16 $ CAD
0.16 $ CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Download

Price may change with quantity see chart under PROMOTIONS


18-8 stainless steel screws have good chemical resistance may be mildly magnetic. A decorative rounded top provides a finished appearance. These screws are beveled under the head for use in countersunk holes. They penetrate 0.025" and thinner sheet metal. Length is measured from the edge of the head.

View full details

Specifications
Product Number VMESO-06010-C
Material 18-8 Stainless Steel
Screw Size No. 6
Screw Size Decimal Equivalent 0.138"
Length 1"
Oval Head Profile Standard

Head
Diameter 0.262"
Height 0.128"
Drive Size No. 2
Drive Style Square
Drill Bit Size No. 32
Drill Bit Decimal Size Equivalent 0.116"
Maximum Drilling Thickness 0.025"
Approximate Threads per Inch 18
Thread Direction Right Hand
Threading Fully Threaded
Tapping Method Thread Forming
Tapping Screw Type A/AB
Head Type Oval
Oval Top Height 0.074"
Countersink Angle 82°
Tip Type Pointed
Shank Cross Section Round
System of Measurement Inch
For Use In Sheet Metal
RoHS RoHS 3 (2015/863/EU) compliant
