Specifications
Product Number | VMESO-08010-C |
Material | 18-8 Stainless Steel |
Screw Size | No. 8 |
Screw Size Decimal Equivalent | 0.164" |
Length | 1" |
Oval Head Profile | Standard |
Head |
|
Diameter | 0.312" |
Height | 0.152" |
Drive Size | No. 2 |
Drive Style | Square |
Drill Bit Size | No. 29 |
Drill Bit Decimal Size Equivalent | 0.136" |
Maximum Drilling Thickness | 0.025" |
Approximate Threads per Inch | 15 |
Thread Direction | Right Hand |
Threading | Fully Threaded |
Tapping Method | Thread Forming |
Tapping Screw Type | A/AB |
Head Type | Oval |
Oval Top Height | 0.088" |
Countersink Angle | 82° |
Tip Type | Pointed |
Shank Cross Section | Round |
System of Measurement | Inch |
For Use In | Sheet Metal |
RoHS | RoHS 3 (2015/863/EU) compliant |
