Specifications
Product Number | VMSPF-00303 |
Thread Size | 3-56 |
Length | 3/8" |
Threading | Fully Threaded |
Head Diameter | 0.193" |
Head Height | 0.071" |
Drive Style | Phillips |
Drive Size | No. 1 |
Material | Passivated 18-8 Stainless Steel |
Hardness | Rockwell B70 |
Tensile Strength | 70,000 psi |
Screw Size Decimal Equivalent | 0.099" |
Thread Type | UNF |
Thread Spacing | Fine |
Thread Fit | Class 2A |
Thread Direction | Right Hand |
Head Type | Rounded |
Rounded Head Style | Pan |
Rounded Head Profile | Standard |
System of Measurement | Inch |
Specifications Met | ASME B18.6.3 |
RoHS | RoHS 3 (2015/863/EU) Compliant |
REACH | REACH (EC 1907/2006) (06/25/2020, 209 SVHC) Compliant |
