Specifications
| Product Number | VPCTF-00001A |
| Head Type | Socket |
| Socket Head Profile | Standard |
| Drive Style | Hex |
| System of Measurement | Inch |
| Thread Direction | Right Hand |
| Thread Size | 0-80 |
| Screw Size Decimal Equivalent | 0.06" |
| Thread Type | UNF |
| Thread Fit | Class 3A |
| Length | 3/16" |
| Threading | Fully Threaded |
| Thread Spacing | Fine |
Head |
|
| Diameter | 0.096" |
| Height | 0.06" |
| Drive Size | 0.050" |
| Material | Black-Oxide Alloy Steel |
| Fastener Strength Grade/Class | Grade 8 |
| Tensile Strength | 170,000 psi |
| Hardness | Rockwell C37 |
| Specifications Met | ASTM A574 |
| REACH | REACH (EC 1907/2006) (07/16/2019, 201 SVHC) Compliant |
| RoHS | RoHS 3 (2015/863/EU) compliant |
