Specifications
Product Number | VPFTF-01005 |
Thread Size | 1/4"-28 |
Length | 1/2" |
Threading | Fully Threaded |
Flat Head Profile | Undercut |
Head Diameter | 0.477" |
Head Height | 0.107" |
Countersink Angle | 82° |
Drive Style | Hex |
Drive Size | 5/32" |
Material | Black-Oxide Alloy Steel |
Hardness | Rockwell C32 |
Tensile Strength | 120,000 psi |
Screw Size Decimal Equivalent | 0.250" |
Thread Type | UNF |
Thread Spacing | Fine |
Thread Fit | Class 3A |
Thread Direction | Right Hand |
Head Type | Flat |
System of Measurement | Inch |
Specifications Met | ASTM F835 |
RoHS | RoHS 3 (2015/863/EU) Compliant |
REACH | REACH (EC 1907/2006) (01/16/2020, 205 SVHC) Compliant |
