Specifications
Product Number | VPSC-03027 |
Head Type | Socket |
Socket Head Profile | Standard |
Drive Style | Hex |
System of Measurement | Inch |
Thread Direction | Right Hand |
Thread Size | 3/8"-16 |
Screw Size Decimal Equivalent | 0.375" |
Thread Type | UNC |
Thread Fit | Class 3A |
Length | 2-3/4" |
Threading | Partially Threaded |
Min. Thread Length | 1-1/4" |
Thread Spacing | Coarse |
Head |
|
Diameter | 9/16" |
Height | 3/8" |
Drive Size | 5/16" |
Tensile Strength | 70,000 psi |
Hardness | Rockwell B70 |
Material | 304 Stainless Steel |
RoHS 3 (2015/863/EU) | Compliant |
