Specifications
Product Number | VPSCM-03035 |
Nominal Diameter | M3 * 0.5mm |
Length | 35mm |
Material and/or Plating | A2 Stainless Steel [Equivalent 304 SS] |
System of Measurement | Metric |
Thread Specifications |
|
Threading | Partially Threaded |
Type | ISO Metric Pitch | Coarse |
Direction | Right Hand |
Size | M3 * 0.5mm |
Min. Length | 18mm |
Fit | Class 5g6g |
Head Specifications |
|
Type | Socket |
Profile | Standard |
Diameter | 5.50mm |
Height | 3.00mm |
Drive Style | Allen Key |
Drive Size | 2.50mm |
Strength Specifications |
|
Strength Grade/Class |
|
Tensile Strength | Hardness | 70,000 psi | Rockwell B70 |
Shear Strength | 42,000 psi |
Classification | DIN 912 |
