Specifications
Product Number | VPSCMT3-20120 |
Nominal Diameter | M20 * 2.5mm |
Length | 120mm |
Material and/or Plating | A4 Stainless Steel [Equivalent 316 SS] |
System of Measurement | Metric |
Thread Specifications |
|
Threading | Fully Threaded |
Type | ISO Metric Pitch | Coarse |
Direction | Right Hand |
Size | M20 * 2.5mm |
Fit | Class 5g6g |
Head Specifications |
|
Type | Socket |
Profile | Standard |
Diameter | 30.00mm |
Height | 20.00mm |
Drive Style | Allen Key |
Drive Size | 17.00mm |
Strength Specifications |
|
Strength Grade/Class |
|
Tensile Strength | Hardness | 75,000 psi | Rockwell B79 |
Shear Strength | 45,000 psi |
Classification | DIN 912 |
