Round Head Self-Drilling Screw 410 Stainless Steel #6 * 1/2" [Square Drive]

Round Head Self-Drilling Screw 410 Stainless Steel #6 * 1/2" [Square Drive]

0.25 $ CAD
0.25 $ CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Download

Price may change with quantity see chart under PROMOTIONS


Stronger and more wear resistant than 18-8 stainless steel, these screws are magnetic and mildly chemical resistant. They save you time and effort by drilling their own holes and fastening in a single operation. Not for use with aluminum. Length is measured from under the head.

View full details

Specifications
Product Number VTARS-06005-C
Material 410 Stainless Steel
Screw Size No. 6
Screw Size Decimal Equivalent 0.138"
Length 1/2"

Drill Tip
Type No. 1
Length 7/64"
Maximum Drilling Thickness 0.035"

Head
Diameter 0.27"
Height 0.097"
Drive Size No. 2
Drive Style Squarre
Approximate Threads per Inch 20
Thread Direction Right Hand
Threading Fully Threaded
Tapping Method Thread Forming
Tapping Screw Type BSD
Head Type Rounded
Rounded Head Profile Standard
Rounded Head Style Pan
Tip Type Drilling
Shank Cross Section Round
System of Measurement Inch
For Use In Steel, Stainless Steel, Sheet Metal
RoHS RoHS 3 (2015/863/EU) compliant
